Lutron RT-616 – 3 Phase Rotation Meter
Stok 5
Lutron RT-616 is a professional contact and non-contact tachometer designed for accurate measurement of rotational speed. It is widely used in industrial maintenance, machinery inspection, and quality control applications.
Status Barang: Preorder (8 minggu)
Kondisi: Baru
Minimal Order: 1 pcs
Rp915.000,0
Stok 5
3 PHASE ROTATION TESTER
Model : RT-616
FEATURES:
◆ Electronic ( not mechanical ) rotation test, high reliability.
◆ LCD display, easy ready and simple operation.
◆ Signal input voltage : 100V AC up to 660V AC max.
EACH UNIT INCLUDES WITH:
◆ Operational manual
◆ Meter with 3 Pcs 40 cm length test lead and banana Plug
◆ Alligator clip, 3pcs
| Berat | 1 kg |
|---|
GENERAL SPECIFICATIONS
|
Signal Input Voltage |
100V AC up to 660 AC maximum, 3 min. limit for over 500V AC. |
|
Signal Current Consumption |
Approx. 7 mA per phase. |
|
Signal Freq. Range |
45 to 70 Hz. |
|
Circuit |
* Electronic ( not mechanical). LSI circuit. |
|
Power Supply |
DC 9V battery. 006P, MN1604 ( PP3 ) or equivalent. Approx. |
|
Power Consumption |
Approx. DC 8 mA. |
|
Operating Temperature |
0 to50°C(32 to122°F). |
|
Operating Humidity |
Less than 80% RH. |
|
Dimension |
100 x 50 x 25 mm. 3.9 x 1.9 x 1.0 inch. |
|
Weight |
150 g/0.33 lb. |
|
Standard Accessories |
* Operational manual……………..1 PC
* Meter with 3 PCs 40 cm length test lead and banana Plug………1 SET * Alligator clip……………………….3 PC |
