Building and Industrial Thermal Imagers
Flir TG267 – Thermal Imaging Camera
Availability:
3 in stock
The FLIR TG267 takes you beyond the limitations of single-spot IR thermometers to both see and evaluate the hot and cold spots that can indicate serious issues. Ideal for commercial electrical, facility maintenance, and HVAC applications, this advanced thermal camera with a brilliant 2.4 inch screen reduces diagnostic time while simplifying repair and maintenance reporting. Patented FLIR MSX (Multi-Spectral Dynamic Imaging) enhancement improves image clarity by embossing visual scene details on full thermal images
Status Barang: Ready
Kondisi: Baru
Minimal Order: 1 pcs
$643.55
3 in stock
OVERVIEW:
The FLIR TG267 takes you beyond the limitations of single-spot IR thermometers to both see and evaluate the hot and cold spots that can indicate serious issues. Ideal for commercial electrical, facility maintenance, and HVAC applications, this advanced thermal camera with a brilliant 2.4 inch screen reduces diagnostic time while simplifying repair and maintenance reporting. Patented FLIR MSX (Multi-Spectral Dynamic Imaging) enhancement improves image clarity by embossing visual scene details on full thermal images
KEY FEATURES:
◆ IR Resolution 160 × 120 pixels
◆ Contact-measurement readings with the included Type-K thermocouple up to 260°C
◆ Identify the exact area that you’re measuring using the bullseye laser pointer
◆ Diagnose problems faster with FLIR-patented MSX image enhancement
◆ Display and capture thermal or visual images with temperature readings
◆ Compare before-and-after stored images with FLIR Tools software to demonstrate the problem and your fix
SPECs:
◆ Temperature Range: -25°C to 380°C
◆ Field of View: 57° x 44°
◆ Minimum Focus Distance: Thermal: 0.3
◆ Image Frequency: 8.7 Hz
◆ Spectral Range: 8μm – 14μm
◆ 320 × 240 pixel, 2.4″ Display (Color)
◆ Storage: Internal memory, with storage capacity: ±50,000 image
◆ Operating time 5 hours continuous scanning, 4.5 hours with laser on
EACH UNIT INCLUDES WITH:
◆ FLIR TG267
◆ Wrist strap lanyard
◆ USB A to USB C cable
◆ Carry Pouch
◆ K Type Thermocouple
◆ Printed documentation
| Weight | 1 kg |
|---|
| Highlighted | |
|---|---|
| IR Resolution | 160 × 120 pixels |
| Thermal Sensitivity/NETD | <70 mK |
| Accuracy | ±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F); up to ±3°C (±5.4°F) for -25°C to 50°C (-13°F to 122°F) and 100°C to 380°C (212°F to 716°F) |
| Field of view (FOV) | 57° × 44° |
| Image Modes | • MSX® (Multi Spectral Dynamic Imaging) • Visual with temperature reading |
| Display | 320 × 240 pixel, 2.4 in color LCD |
| Storage Media | eMMC 4 GB |
| Imaging & Optical | |
|---|---|
| Built-in Digital Camera | Yes |
| Color Palettes | Iron, Rainbow, White hot, Black hot, Arctic, Lava |
| Detector Pitch | 12 µm |
| Detector Type | Focal plane array (FPA), uncooled microbolometer |
| Digital image enhancement | Yes |
| Field of view (FOV) | 57° × 44° |
| Focus | Focus free |
| Gallery | Yes |
| Image Frequency | 8.7 Hz |
| Image Modes | • MSX® (Multi Spectral Dynamic Imaging) • Visual with temperature reading |
| IR Resolution | 160 × 120 pixels |
| Laser | Class 1 laser indicates the temperature measurement area; button-activated |
| Minimum Focus Distance | 0.3 m (0.98 ft) |
| Minimum Measurement Distance | 0.26 m (0.85 ft) |
| Spectral Range | 7.5 – 14 µm |
| Thermal Sensitivity/NETD | <70 mK |
| Measurement & Analysis | |
|---|---|
| Accuracy | ±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F); up to ±3°C (±5.4°F) for -25°C to 50°C (-13°F to 122°F) and 100°C to 380°C (212°F to 716°F) |
| Camera size (L x W x H) | 210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in) |
| Camera weight incl battery | 0.394 kg (13.9 oz) |
| Center spot | Yes |
| Emissivity Correction | Yes: 4 preset levels with custom adjustment of 0.1–0.99 |
| Object Temperature Range | -25°C to 380°C (-13°F to 716°F) |
| Set-up Commands | • Local adaptation of units, language, date, and time formats • Screen brightness (high, medium, low) • Gallery, deletion of images |
| Spot Meter | Center spot on/off |
| User Interface | |
|---|---|
| Display | 320 × 240 pixel, 2.4 in color LCD |
| Languages | Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish. |
| Communication & Data Storage | |
|---|---|
| Image Storage Capacity | 4 GB for storage of up to 50,000 pictures |
| Interface | USB 2.0, Bluetooth |
| Memory Type | Internal |
| Saved image format | JPEG |
| Storage Media | eMMC 4 GB |
| USB | USB Type-C: data transfer/power |
| USB – Standard | USB 2.0 High Speed |
| Power | |
|---|---|
| Battery charge life | 30 days minimum |
| Battery operating time | 5 hours continuous scanning, 4.5 hours with laser on |
| Battery Type | Rechargeable Li ion battery |
| Battery voltage | 3.7 V |
| Charging system | Battery is charged inside the camera |
| Charging Temperature | 0°C to 45°C (32°F to 113°F) |
| Charging Time | 4 hours to 90%, 6 hours to 100% |
| Power Management | Adjustable: off, 5 min., 15 min., 30 min. |
| Environmental & Certifications | |
|---|---|
| Certifications | CE, CB, RCM, IEC60825-1, FDA, UL, CEC, NRCan |
| Drop test | Designed for 2 m (6.6 ft) |
| EMC | • EN 61000-6-3 • EN 61000-6-2 • FCC 47 CFR Part 15 Class B |
| Encapsulation | IP 54 (IEC60529) |
| Humidity (Operating and Storage) | 0-90% RH (0-37°C (32-98.6°F)), 0-65% RH (37-45°C (98.6-113°F)), 0-45% RH (45-55°C (113-131°F)) |
| Operating Temperature Range | -10°C to 45°C (14°F to 113°F) |
| Radio Spectrum | • ETSI EN 300 328 • FCC Part 15.249 • RSS-247 Issue 2 • EN 301 489-1:2011 • EN 301 489-17:2009 |
| Safety | CE/CB/EN61010/UL |
| Shock | 25 g (IEC 60068-2-27) |
| Storage Temperature Range | -30°C to 55°C (-22°F to 131°F) |
| Tripod Mounting | 1/4 in.-20 on handle bottom |
| Vibration | 2 g (IEC 60068-2-6) |
| General | |
|---|---|
| Includes | TG267, printed documentation, wrist strap lanyard, USB A to USB C cable, carry pouch |
